Customer Account API with Headless

Authentication & Access
,
1

Environment

  • App Type: Confidential (Headless)

  • Store: Development store with password protection enabled

  • API: Customer Account API (GraphQL)

  • Authentication: OAuth 2.0 with PKCE

Issue Description

I’ve successfully implemented the OAuth flow for the Customer Account API and am receiving valid access tokens. However, when I attempt to call the Customer Account API GraphQL endpoint, I receive a 302 redirect to /password instead of the expected API response.

OAuth Flow (Working Successfully :white_check_mark:)

  1. Authorization request to: https://shopify.com/authentication/{shop_id}/oauth/authorize

  2. Token exchange to: https://shopify.com/authentication/{shop_id}/oauth/token

  3. Successfully receiving:

    • access_token (544 characters, starting with shcat_)

    • refresh_token

    • id_token

    • Scopes: openid email customer-account-api:full

Token Exchange Request (Confidential Client)

POST https://shopify.com/authentication/{shop_id}/oauth/token
Content-Type: application/x-www-form-urlencoded
Authorization: Basic {base64(client_id:client_secret)}

grant_type=authorization_code
client_id={client_id}
redirect_uri={redirect_uri}
code={authorization_code}
code_verifier={pkce_verifier}

GraphQL API Request (Failing :cross_mark:)

Endpoint: https://{shop}.myshopify.com/customer/api/graphql

Postman Request:

Method: POST
URL: https://{shop}.myshopify.com/customer/api/graphql

Headers:
  Authorization: {access_token}
  Content-Type: application/json

Body (raw JSON):
{
  "query": "query { customer { id firstName lastName } }"
}

Response:

HTTP/2 302 Found
Location: https://{shop}.myshopify.com/password

What I’ve Verified

  1. :white_check_mark: Access token format is correct (starts with shcat_, 544 characters)

  2. :white_check_mark: Token exchange uses Basic Auth header as required for Confidential clients

  3. :white_check_mark: Discovery endpoint works: /.well-known/customer-account-api returns the GraphQL URL

  4. :white_check_mark: Scopes match the supported scopes from /.well-known/openid-configuration

  5. :white_check_mark: Authorization header contains only the access token (no “Bearer” prefix, per Shopify docs)

  6. :white_check_mark: Tested in both Postman and backend server implementation (Go) - same result

Questions

  1. Does password protection on a development store block Customer Account API access even with valid access tokens?

  2. Is there a configuration setting to allow API access on password-protected dev stores?

  3. Should I remove password protection for API testing, or is there something I’m missing in my implementation?

Additional Context

  • The OAuth flow completes successfully without any errors

  • The access token is valid (not expired)

  • This is a backend server implementation using the Confidential client type

  • Same behavior occurs in both automated requests and manual Postman testing

Any guidance would be greatly appreciated!

2

brother i’m in the same boat as you. i confirmed the other day with shopify support that this doesn’t work on a password protected dev store.

i’m testing this on a store with a paid plan but now the graphql endpoint is returning 404…

3

if there’s anyone else out there struggling with this particular problem don’t use the graphql endpoint that the discovery endpoint gives you. try using this instead:

https://shopify.com/{shop_id}/account/customer/api/{api_version}/graphql

this was a ballache to search for but thankfully came across this blogpost here:

4

Thank you very much! This seems to work. I have been in contact with Shopify support and I will make sure to escalate this issue to their technical teams. Their docs are not correct and their own discovery endpoints are returning incorrect data. A lot of wasted dev hours on bad documentation from their end.
